Sony FCB Regular Version Block Cameras for System Integration
The Regular Version refers to Sony FCB zoom modules in factory-standard form. Units ship with original LVDS digital video, VISCA serial control, default firmware, and unmodified mechanics. This stock configuration provides broad compatibility, stable lifecycle support, and short lead times for teams building on a proven baseline.
Why this baseline helps integrators
- Works out of the box with our interface boards to convert LVDS into production formats without altering the camera core.
- Faster evaluation and deployment, with consistent controls and image tuning across models.
- Suitable for secondary development where acquisition, conversion, transmission, and processing are tailored to the project.
Model highlights
- FCB‑ER9500 Regular Version (4K/60fps, 25x): Flagship 4K capture with WDR, Auto ICR, and fast AF for UAVs, smart traffic, and inspection. Pair with our boards for simultaneous HDMI, network streaming, and USB3.0 output.
- FCB‑ER9100 Regular Version (4K/60p, 10x): Compact 4K option balancing size and performance for robotics, ITS, and mobile platforms. Extend I/O to SDI, IP, or USB easily.
- FCB‑EV9520L Regular Version (Full HD, 30x): Proven 1080p/30x block with strong low‑light clarity and stable autofocus. Cost‑effective choice for surveillance, conferencing, and medical video.
Interface boards and output options
Our in‑house boards bridge LVDS to production‑ready formats while preserving the unmodified camera. The VRS‑UD410 (4K/60, AI‑capable) supports simultaneous HDMI, network, and USB3.0/UVC. Options include 3G/6G/12G‑SDI, MIPI, Type‑C, and CVBS. Combine multiple outputs to feed recorders, encoders, and machine processors in parallel with minimal integration time.
Applications
These modules serve security/CCTV, UAVs, smart healthcare, video conferencing, robotics, industrial testing, machine vision, and ROV/AUV. Image quality stays consistent, while the boards adapt outputs and connectors to each scenario. For aerial work, ER9500/ER9100 can operate alongside the Sony ILX‑LR1 in mapping or inspection workflows.
Quick specs snapshot
- ER9500: 4K/60fps, 25x optical zoom, WDR, Auto ICR, LVDS video, VISCA control.
- ER9100: 4K/60p, 10x optical zoom, LVDS video, VISCA control.
- EV9520L: Full HD 1080p, 30x optical zoom, LVDS video, VISCA control.
- Boards: HDMI, IP streaming, USB3.0/UVC, SDI (3G/6G/12G), MIPI, Type‑C, CVBS; simultaneous outputs supported.
- Services: Custom form‑factor boards, connectors, power, and firmware profiles; rapid development backed by 16 years of board R&D and 25 years with Sony FCB modules.
Integration benefits
- Standard mechanics and interfaces simplify mounting and wiring.
- Plug‑and‑play conversion reduces steps and risk during development.
- Scalable path from 1080p to 4K; optional AI on VRS‑UD410 when needed.
Proven supply and support
As an Official Sony (China) authorized distributor and HD video development partner, we provide genuine modules, technical guidance, and responsive after‑sales. Our portfolio includes utility model patents and software copyrights that support maintainable integrations.
FAQ
- Q: What does “Regular Version” change compared to customized modules?
- A: It keeps Sony’s factory video, control, firmware, and mechanics intact. Expansion happens on the interface board, not inside the camera.
- Q: Can I get simultaneous HDMI, IP, and USB3.0?
- A: Yes. The VRS‑UD410 supports concurrent outputs and can be configured with SDI, MIPI, Type‑C, or CVBS as needed.
- Q: Do these modules support VISCA over serial?
- A: Yes. VISCA serial control remains unchanged, and our boards expose practical ports while passing control transparently.
- Q: How fast can I evaluate and deploy?
- A: Most teams prototype within days by pairing the camera with a suitable board and using default firmware profiles.
Contact Regular Version Supplier for Sony FCB Modules
Request a quote or engineering consultation. We help with model selection, interface board matching, and custom development—delivering a smooth path from evaluation to deployment.
